PJD6381 is a portable, high-brightness, high-contrast projector with BrilliantColor technology, which provides lifelike colors, sharp graphics and outstanding video quality. Eco-mode mode can extend the lamp life, and network control function can remotely manage and monitor the projector and lamp status. Direct off function allows users to unplug the power without waiting for the cooling time. The short throw lens can project a large image in a small space.
The PJD6381 is an ultra‑short‑throw projector that delivers up to 2700 ANSI lumens and a 3500:1 contrast ratio in a compact 2.68 kg package. It features a 0.68:1 throw ratio, 120 Hz refresh rate, 3D readiness, and a DLP® light engine with a six‑segment color wheel for vivid color reproduction.
The manual covers network control via RJ‑45, eco‑mode lamp extensions, on‑the‑fly adjustments such as digital keystone correction, and detailed connector options. It also lists operating temperature ranges, dimensions, and accessories included with the projector.
| Display Type | 0.55" Digital Micromirror Device (DLP™) |
|---|---|
| Resolution | XGA 1024x768 (Native) / UXGA 1600x1200 (compressed) |
| Throw Ratio | 0.68:1 |
| Brightness | 2700 ANSI Lumens |
| Contrast Ratio | 3500:1 (with DCR) |
| Lamp Life | 4000 h normal / 6000 h Eco |
| Weight | 2.68 kg (5.9 lb) |
| Dimensions | 280 × 114 × 218 mm (11 × 4.5 × 8.58 in) |
| Power Input | 12 V DC Connector |
| RGB Input Connector | 2 × 15‑pin D‑sub |
The lamp lasts 4000 hours in normal mode and up to 6000 hours in Eco mode.
The projector has a throw ratio of 0.68:1.
It can be managed via an RJ‑45 network connection.
The unit weighs 2.68 kg (5.9 lb).
