ViewSonic VFM1034W 10-inch high-resolution digital photo frame, supports USB interface, built-in 128MB storage space, can play MP3 music
The VFM1034W is a 10‑inch digital photo frame with a 1024 × 600 LCD display, built‑in 128 MB memory, and USB 2.0 host/slave connectivity for easy photo, video, and music playback. It includes clock, calendar, and alarm functions, and supports a wide range of image and media file formats.
Technical details include a contrast ratio of 400:1 (typical), brightness of 280 cd/m², and viewing angles of 140° horizontal and 110° vertical. Power requirements are 100‑240 VAC (auto‑switching) with a consumption of 11 W. The unit measures 313 mm × 260 mm × 66 mm and weighs 1.7 kg, and it complies with FCC and CE regulations. This manual is written in German.
| Display size | 10" color TFT active matrix LCD/LED Backlight |
|---|---|
| Resolution | 1024x600 |
| Contrast ratio | 400:1 (typ) / 300:1 (rin) |
| Viewing angles | 140° horizontal, 110° vertical |
| Brightness | 280 cd/m² (typ) |
| Internal memory | 128 MB |
| Supported image formats | JPEG, CF, SD, SDHC, MMC, MS, MS Pra, XD |
| Supported audio/video formats | MP3, MPEG‑1, MPEG‑4 (avi), DivX, Xvid, MPEG‑2 |
| Power input | 100‑240 VAC, 50/60 Hz (auto‑switching) |
| Power consumption | 11 W |
| Dimensions (W×H×D) | 313 mm × 260 mm × 66 mm |
| Weight | 1.7 kg |
The frame has a 1024 × 600 pixel LCD display.
It includes 128 MB of built‑in memory.
It operates on 100‑240 VAC, 50/60 Hz and consumes about 11 W.
Supported image formats include JPEG, CF, SD, SDHC, MMC, MS, MS Pra, XD; audio/video formats include MP3, MPEG‑1, MPEG‑4 (avi), DivX, Xvid, MPEG‑2.
