Amprobe HD160C Heavy-Duty Digital Multimeter is a rugged autoranging meter with true-rms function that can measure up to 1500 Vdc and 1000 Vac CAT IV 1000 V, and has IP67 waterproof rating. It can also measure capacitance, temperature and frequency.
The HD160C Heavy‑Duty Digital Multimeter is built for professional use in harsh environments. It features a drop‑resistant housing, fire‑retardant thermoplastic construction, and an IP67 rating for water and dust protection. The meter provides true‑RMS measurements, a 10 000‑count resolution, and a bright Digi‑Glo™ backlight.
Technical specifications include a voltage range up to 1500 V DC and 1000 V AC (CAT IV), capacitance, temperature, and frequency measurements, as well as high‑resolution displays and bar‑graph indicators. The unit ships with heavy‑duty test leads, a Magne‑Grip™ holster, and optional accessories for extended functionality.
| Maximum voltage measurement | 1500 V DC / 1000 V AC (CAT IV) |
|---|---|
| IP rating | IP67 |
| Resolution (DC voltage) | 0.1 mV in 1000 mV range |
| Battery life (typical) | 150 hours (alkaline) |
| Dimensions (without holster) | 200 × 102 × 59 mm |
| Weight (incl. battery) | 642 g (22 oz) |
| Input impedance | 10 MΩ |
| Transient protection | 12 kV impulse |
The HD160C can measure up to 1500 V DC and 1000 V AC, meeting CAT IV requirements.
The meter is rated IP67, providing protection against dust and water immersion.
Included are heavy‑duty CAT IV 1000 V test leads, an installed battery, a hex wrench, a Magne‑Grip™ holster, a Type K thermocouple probe, a temperature adaptor, and the user manual.
