The Premium 10502 is a high‑performance CD‑engine module designed for professional audio/video applications. This manual describes the system architecture, connector layout, DSA control interface, power requirements, and optional configuration options.
It also includes wiring diagrams, power‑supply grounding instructions, and a problem‑solving section that helps diagnose common start‑up issues such as sledge movement and focus errors.
| Software version | Version 6.x |
|---|---|
| Software ROM size | About 32k bytes |
| Laser power | 375 pW |
| HF signal amplitude | 1.0 V pp (measured at HFIN) |
| Focus bandwidth | 1000 Hz |
| Radial bandwidth | 1200 Hz |
| Audio output level | 1.5 Veff |
| Audio output impedance | 110 Ω |
