74HC1G14/74HCT1G14 is a high-speed Si-gate CMOS device. It provides the inverting buffer function with Schmitt-trigger action. These devices are capable of transforming slowly changing input signals into sharply defined, jitter-free output signals. The standard output currents are 1⁄2 compared to the 74HC/HCT14.
The 74HC1G14 and 74HCT1G14 are high‑speed CMOS inverting Schmitt‑trigger buffers with wide operating voltage range and low power dissipation. They are intended for wave and pulse shaping, astable and monostable multivibrators, and other digital logic applications.
Key data include a supply voltage range of 2.0 V to 6.0 V, typical propagation delay of 6.0 ns, and power dissipation up to 200 mW. The devices are offered in 5‑pin SC‑88A (SOT‑353) and SC‑74A (SOT‑753) plastic packages and operate from –40 °C to +125 °C.
| Supply voltage range | 2.0 V to 6.0 V |
|---|---|
| Typical propagation delay | 6.0 ns |
| Package (SC‑88A) | 5‑pin plastic SOT‑353 |
| Operating temperature range | -40 °C to +125 °C |
The devices operate from 2.0 V up to 6.0 V.
They are supplied in 5‑pin SC‑88A plastic SOT‑353 and SC‑74A plastic SOT‑753 packages.
Typical propagation delay is 6.0 ns.
The recommended temperature range is –40 °C to +125 °C.
