The BAS16W is a high-speed switching diode with a very small plastic SMD package. It features high switching speed, maximum continuous reverse voltage of 75V, maximum repetitive peak reverse voltage of 85V, and maximum repetitive peak forward current of 500mA.
The BAS16W is a high‑speed PIN diode offered by Philips Semiconductors in a compact SOT323 (SC‑70) surface‑mount package. It is intended for high‑speed switching applications in surface‑mounted circuits.
The document lists key electrical limits such as a 85 V repetitive peak reverse voltage, 500 mA peak forward current, 75 V continuous reverse voltage, and a typical forward voltage of 855 mV at 10 mA. Thermal data, diode capacitance, reverse‑recovery time, and package dimensions are also provided.
| Repetitive peak reverse voltage | 85 V |
|---|---|
| Continuous reverse voltage | 75 V |
| Repetitive peak forward current | 500 mA |
| Forward voltage at 10 mA | 855 mV |
| Forward voltage at 150 mA | 1.25 V |
The BAS16W can withstand up to 85 V repetitive peak reverse voltage.
It is supplied in a plastic SOT323 (SC‑70) surface‑mount package with three leads.
The forward voltage is about 855 mV when the diode conducts 10 mA.
