The ZXGD3004E6 is a high-speed non-inverting single MOSFET gate driver capable of driving up to 8A into a MOSFET or IGBT gate capacitive load from supply voltages up to 40V. With typical propagation delay times down to ~1ns and rise/fall times down to 14ns, this device ensures rapid switching of the power MOSFET or IGBT to minimize power losses and distortion in high current fast switching applications. The ZXGD3004E6 is inherently rugged to latch-up and shoot-through, and its wide supply voltage range allows full enhancement to minimize on-losses of the power MOSFET or IGBT. Its low input voltage requirement and high current gain allows high current driving from low voltage controller ICs, and the optimized pin-out SOT23-6 package with separate source and sink pins eases board layout, enabling reduced parasitic inductance and independent control of rise and fall slew rates.
The ZXGD3004E6 is a non‑inverting single MOSFET/IGBT gate driver that can deliver up to 8 A peak output current from supply voltages up to 40 V. It features a fast propagation delay of about 1 ns and rise/fall times of 14 ns, making it suitable for high‑current, fast‑switching applications.
The device is supplied in a compact SOT23‑6 package with separate source and sink pins for easy board layout. It includes low input current requirements, near‑zero quiescent leakage, and is rugged against latch‑up and shoot‑through. Detailed electrical characteristics, absolute maximum ratings, and package dimensions are provided in the datasheet.
| Operating voltage range | 40 V |
|---|---|
| Peak output current | 8 A |
| Typical propagation delay | ~1 ns |
| Rise/fall time | 14 ns |
| Quiescent current | 50 nA |
| Input current | 1 A |
| Power dissipation (Tj=25 °C) | 11 W |
| Package type | SOT23‑6 |
The device can operate with a supply voltage up to 40 V.
The typical propagation delay is about 1 ns.
It can deliver a peak output current of 8 A.
The quiescent current is 50 nA.
