This manual introduces the basic function and usage of the electronic pressure switch DS 4.
This manual describes the DS4 electronic pressure switch, designed for pneumatic and vacuum applications. It includes safety warnings, product identification, installation steps, electrical connection, initial start‑up, operation settings, maintenance, warranty and fault handling.
The document is intended for professional technicians and provides detailed procedures for mounting the pressure interface (G1/8" and M5 threads), connecting the sensor electrically, configuring parameters via the CIS‑680/681 programming adapter, and cleaning or returning the unit for service. This manual is written in Chinese.
| Rated pressure range | 0‑10 bar |
|---|---|
| Material of housing | PA6.6 |
| Sensor type | Silicon sensor |
| Maximum tightening torque (G1/8" thread) | 3 Nm |
| Maximum tightening torque (M5 thread) | 1 Nm |
| Switch function | Normally open (NO) |
| Switch mode | Hysteresis mode |
The package should contain the DS4 pressure switch and the installation instructions.
