This document describes the features and characteristics of 3M Telecommunications products, including connectors for PCB applications, technical modules, modules for large cables, bus termination units, and screwtype strips/boxes.
The Quante Specialty Connectors catalog presents a range of connector modules designed for printed‑circuit‑board (PCB) and large‑cable installations. Series such as SJS, SID‑P, SID‑CP, DE and BR2 provide various pole counts, mounting options, and protection features.
Each module includes detailed mechanical dimensions, contact counts, and electrical characteristics, enabling designers to select the appropriate connector for telephony, industrial, or distribution applications. Accessories and tools for installation are also listed.
| SJS IDC contacts per module | 12, 32, 40 |
|---|---|
| Maximum conductor diameter (BR2) | 1.5 mm |
| Dielectric strength (BR2) | 1000 V AC 50 Hz |
| IP rating (BR2) | IP34 |
The BR2 box has an IP34 protection rating.
The BR2 box supports conductors up to 1.5 mm in diameter.
SJS modules are offered with 12, 32, or 40 IDC contacts.
