3M Crimplok™ Connectors are quick, easy to install connectors that offer superior performance. These connectors combine the speed of non-adhesive connectors with the performance characteristics of epoxy and hot melt connectors. Crimplok connectors are the ideal solution for quickly making fiber connections at the desk or for emergency restoration work. They save installation time, provide rugged, reliable performance, and are easy to install.
The 3M Crimplok™ connectors provide a quick, easy‑to‑install solution for fiber optic terminations. Designed for both multimode (SC, ST) and single‑mode (SC, ST) applications, they combine a non‑adhesive design with a malleable metal element that grips the fiber without added attenuation.
Installation requires only minimal tools—no electricity or special heating equipment—and can be completed in under two minutes. The connectors meet or exceed EIA/TIA‑568A specifications and are rated for 500 mating cycles, making them suitable for both desk‑side repairs and permanent wiring installations.
| Attenuation @ 1300 mm (multimode SC) | <0.2 dB typical |
|---|---|
| Reflection (multimode SC) | <‑29 dB typical |
| Operational temperature | -10 °C to 60 °C |
| Storage temperature | -40 °C to 80 °C |
| Mating durability | 500 matings |
Only a small activation tool and a few basic hand tools are required; they can be stored in a small tool pouch.
No, the installation process does not require any electricity.
Each connector is rated for up to 500 mating cycles.
The typical insertion loss is less than 0.2 dB at 1300 mm.
