The SPUJ series is a 2-millimeter travel horizontal switch from Omron, available in 2-pole and 4-pole configurations, non-shorting types, push-button and dial operation, button and dial types, pull-type and momentary types.
The SPUJ series push switches are horizontal‑type tactile switches offered in 2‑pole and 4‑pole versions. They feature a 2 mm travel, 5 mm lever height, and are suitable for a variety of electronic and automotive applications.
The document provides electrical ratings such as a 0.1 A / 30 V DC resistive load, contact resistance values, and environmental performance including operating temperature from –40 °C to 85 °C. Mechanical details cover mounting hole dimensions, knob options, and durability specifications up to 10,000 cycles. This manual is written in Chinese.
| Resistive load | 0.1 A / 30 V DC |
|---|---|
| Contact resistance (initial) | Not specified |
| Travel | 2 mm |
| Lever height | 5 mm |
| Operating life (no load) | 10,000 cycles |
| Operating temperature range | -40 °C to 85 °C |
| Insulation resistance | 500 V DC |
The switches can handle a resistive load of up to 0.1 A at 30 V DC.
The switches are rated for 10,000 cycles without load.
The actuator travel is 2 mm.
The device operates from –40 °C up to 85 °C.
