3M Scotch™ 9545 is a heavy-duty cloth tape, which is ideal for the identification of electrical wires and equipment. The wide range of colours and widths, coupled with being easy to write on means that the tape is very versatile.
Scotch™ 9545 cloth tape is a heavy‑duty, impregnated‑viscose fabric tape designed for electrical wire and equipment identification. It is easy to write on, can be torn without scissors, and offers strong longitudinal strength for harnessing applications.
Technical data include a 10 m length, 0.27 mm thickness, and widths of 12, 19 and 25 mm (other widths on request). The tape is available in seven colors and features a natural‑rubber adhesive with 78 N/25 mm adhesive strength and 280 N/25 mm tensile strength.
| Length | 10 m |
|---|---|
| Thickness | 0.27 mm |
| Widths | 12, 19 and 25 mm |
| Colours | Blue, red, yellow, green, black, white, grey |
| Material | Impregnated viscose fabric |
| Adhesive | Natural rubber |
| Adhesive strength | 78 N/25 mm |
| Tensile strength | 280 N/25 mm |
The tape is offered in blue, red, yellow, green, black, white and grey.
Yes, the tape can be torn without scissors.
The adhesive strength is 78 N per 25 mm.
