ASDA-M series servo drive and ECMA series servo motor
This manual provides detailed instructions for the Delta ASDA-M series servo drives, including safety precautions, installation steps, wiring guidelines, parameter settings, and routine maintenance. It is intended for system designers, installers, commissioning engineers, and service technicians.
The document also contains troubleshooting advice, inspection procedures, and appendices with basic test items and parameter reset instructions, ensuring reliable operation in industrial environments. This manual is written in Chinese.
| Maximum signal wiring length | 3 m (9.84 ft) |
|---|---|
| Maximum PG cable length | 20 m (65.62 ft) |
Connect the grounding protection terminal to a class‑3 grounding system (≤ 1000 Ω).
