This quick start guide introduces the features and characteristics of the Delta 1010LT Digital PCI Audio Card.
The Delta 1010LT is a 10‑input, 10‑output digital PCI audio card from M‑Audio that offers 24‑bit/96 kHz full‑duplex recording, eight balanced XLR analog inputs, eight RCA analog outputs, and S/PDIF digital I/O. It includes a hardware digital mixer, MIDI I/O, and word‑clock synchronization for professional audio and MIDI production.
The manual walks you through hardware installation, jumper configuration for mic or line‑level inputs, driver installation on Windows and Mac, and use of the Delta Control Panel software for routing, monitoring, and mixing. System requirements, breakout‑cable pin‑outs, and troubleshooting tips are also covered.
| Analog I/O | 8 balanced XLR inputs + 8 RCA inputs, 8 balanced XLR outputs + 8 RCA outputs |
|---|---|
| Dynamic Range (A‑weighted) – Output | 101.5 dB |
| THD (0 dBFS) | < 0.002 % |
| Frequency Response | 22 Hz – 22 kHz (‑0.2, ‑0.4 dB @48 kHz); 22 Hz – 40 kHz (‑0.2, ‑0.7 dB @96 kHz) |
| Maximum Sampling Rate | 96 kHz (24‑bit) |
The analog outputs have a dynamic range of 101.5 dB (A‑weighted).
