MC68HC908AP Family Data Sheet, Rev. 3, introduces the features and characteristics of the product family, including pins, package, electrical characteristics, working temperature range, internal resources, programmers, etc.
This datasheet describes the MC68HC908AP family of 8‑bit microcontrollers, covering general description, memory architecture, configuration registers, CPU core, oscillator and clock generator modules, and peripheral interfaces. It includes detailed electrical and mechanical specifications, pin assignments, and ordering information.
The document is organized into chapters that detail each functional block, such as the Serial Communications Interface (SCI), Serial Peripheral Interface (SPI), Analog‑to‑Digital Converter (ADC), and various interrupt modules. Revision history and contact information for Freescale Semiconductor are provided at the end of the file.
It is Revision 3, dated August 2005.
Freescale™ and the Freescale logo are trademarks of Freescale Semiconductor, Inc.
