This document is the user's guide of Microchip MCP1601 Evaluation Board
This guide introduces the MCP1601 Evaluation Board (Rev 1), a development tool that lets engineers emulate and debug firmware on a target board. It describes the board’s purpose, key features, and what is included in the kit.
The document provides detailed instructions for getting started, test‑point usage, schematic and layout diagrams, and a complete bill‑of‑materials with part numbers and values. Contact information for worldwide sales and technical support is also listed.
