This manual describes the use of the MCP1650/1/2/3 evaluation board. The evaluation board includes power, MCP1650/1/2/3 controller and peripheral devices, which can be used to evaluate the MCP1650/1/2/3 controller's function.
The MCP1650/1/2/3 Evaluation Board is a development platform for evaluating Microchip's MCP1650, MCP1651, MCP1652 and MCP1653 boost‑controller devices. It demonstrates two high‑power boost‑converter applications, one delivering 5 V and the other 12 V.
The guide covers product overview, installation and operation procedures, detailed schematics and layout diagrams, a complete bill of materials, and worldwide sales and service contacts. It also lists recommended reading and customer‑support channels.
| MCP1651 application input voltage range | 2.8 V to 4.8 V |
|---|---|
| MCP1651 application output voltage | 5 V |
| MCP1653 application input voltage | 3.3 V |
| MCP1653 application output voltage | 12 V |
It is used to evaluate and demonstrate Microchip Technology’s MCP1650/51/52/53 Boost Controller product family.
The kit includes the MCP1650 Boost Controller Evaluation Board, this User’s Guide, and the MCP1650/51/52/53 Data Sheet.
You can contact your distributor, local sales office, field application engineer, corporate applications engineer, or call the hot line numbers listed in the guide.
