The product is an EZ-Color HB LED controller that supports up to 4 independent LED channels and 8-32 bits of resolution per channel. It also supports dynamic reconfiguration and other features such as CapSense, battery charging, and motor control.
The CY8CLED04 EZ-Color™ HB LED Controller is a configurable high‑brightness LED driver that supports up to four independent LED channels with 8‑32 bit resolution per channel. It integrates Cypress' PrISM modulation technology to reduce EMI and low‑frequency flicker, and includes a rich set of mixed‑signal peripherals such as ADCs, DACs, UARTs, SPI, I²C, and full‑speed USB.
The device is built on a PSoC® core with 16 KB Flash, 1 KB SRAM, and optional EEPROM emulation. It offers flexible pin configurations, 25 mA sink capability on all GPIOs, and a variety of analog blocks for signal processing, making it suitable for applications like LCD backlights, architectural lighting, flashlights, and camera flashes.
| SRAM Size | 1 KB |
|---|---|
| Flash Size | 16 KB |
| Resolution per Channel | 8‑32 bits |
| USB Speed | Full‑Speed 12 Mbps |
Each channel can be configured for 8 to 32 bits of resolution.
It includes a full‑speed USB interface operating at 12 Mbps.
The device contains 16 KB of flash memory for program storage.
