EC4P-221-MTXD1 is a modular controller with 24 V DC, Can, 12 I, 8 transistor, display, and can be extended with inputs/outputs and bus systems.
The EC4P-221-MTXD1 is a compact easy‑NET/CANopen controller with digital and analog inputs, relay outputs and a built‑in display. It is designed for industrial automation and can be expanded with additional modules.
The manual covers general product data, environmental limits, electrical characteristics, wiring diagrams, installation instructions, and detailed specifications for inputs, outputs, power supply, and communication interfaces.
| Supply voltage | 24 V DC |
|---|---|
| Relay output current | 8 A |
| Digital inputs | 12 |
| Analog inputs | 4 |
| Weight | 0.32 kg |
| Operating temperature | 0 °C … 55 °C |
| Storage temperature | -40 °C … 70 °C |
| Air pressure (operation) | 795 hPa … 1080 hPa |
The controller operates from a 24 V DC supply.
It provides 12 digital inputs.
Each relay output can handle up to 8 A.
Yes, four of the digital inputs can be used as analog inputs.
