This document describes the features and characteristics of the MFD-CP8-ME product, including the suitable interface, power supply requirements, backup function, installation method, terminal capacity, and environmental conditions.
The MFD CP ME cage clamp terminals are IP20‑rated devices intended for secure connections in industrial control panels. The manual lists ordering information, mechanical mounting options, and environmental requirements.
Key specifications include a 24 V DC power supply, operating temperature range of –40 °C to +70 °C, and compliance with IEC/EN standards for EMC, vibration, and shock. Dimensions and mounting details are provided for both display‑shaft and top‑hat rail installations.
| Rated operational voltage | 24 V DC |
|---|---|
| Mounting position | horizontal, vertical |
| Dimensions | 38.75 × 30 × 20.2 mm |
The terminals are rated for a 24 V DC power supply.
They can be fitted onto the fixing shaft of a display or onto a top‑hat rail with a mounting plate thickness of 1 – 6 mm.
