LSE-02 is an adjustable electromagnetic contactor with visible status display and conditional short-circuit restart function.
This handbook describes the LSE‑02 safety relay, including its basic unit features, contact configuration, and auxiliary contacts for safety functions. It lists the applicable standards (EN 60947‑5‑1, IEC 60068‑2‑78, IEC 60068‑2‑30) and environmental ratings such as IP66/IP67.
Technical data cover the rated voltage range (12‑30 VDC), operational currents for 12 V, 24 V and 30 V supplies, ambient temperature limits, mechanical variables, and electromagnetic compatibility requirements. Installation notes, wiring examples, and torque specifications for mounting are also included.
| Rated voltage | 12‑30 VDC |
|---|---|
| Rated operational current (12 V) | 0.015 A |
| Rated operational current (24 V) | 18 mA |
| Rated operational current (30 V) | 0.019 A |
| Protection type | IP66, IP67 |
| Ambient temperature range | 25 °C – 470 °C |
| Operating frequency | 3000 operations/h |
| Repetition accuracy | 0.02 mm |
The LSE‑02 is rated IP66 and IP67.
The relay operates from 12 VDC to 30 VDC.
At 12 V the current is 0.015 A, at 24 V it is 18 mA, and at 30 V it is 0.019 A.
The device can handle up to 3000 operations per hour.
