This document is the detailed information of EC4P-221-MTAX1 product, including product features, specifications, prices, ordering information, etc.
This manual describes the EC4P‑221‑MTAX1 control module, a 24 V DC easy‑NET/CANopen device with 12 digital inputs (4 usable as analog), 6 relay outputs rated at 8 A, and optional LCD status display. It includes ordering information, connection diagrams, and configuration options for bus systems and expansion modules.
Technical data such as dimensions (107.5 × 90 × 72 mm), weight (0.32 kg), operating temperature range (0 °C – 55 °C), and environmental ratings (IP20, IEC/EN standards) are listed, along with details on power supply, isolation, and protection features.
| Supply voltage | 24 V DC |
|---|---|
| Digital inputs | 12 |
| Relay outputs | 6 × 8 A |
| Storage temperature range | 40 °C – 470 °C |
| Weight | 0.32 kg |
The module operates from a 24 V DC supply.
It provides 12 digital inputs, four of which can be used as analog inputs.
The device has six relay outputs, each rated for 8 A.
