The IPP90R500C3 CoolMOS™ Power Transistor features the lowest RON x Qg figure-of-merit, extreme dv/dt rating, and high peak current capability. It is qualified according to JEDEC1) for target applications and is lead-free with lead plating, RoHS compliant, and features ultra low gate charge. CoolMOS™ 900V is designed for Quasi Resonant Flyback / Forward topologies, PC Silverbox and consumer applications, and Industrial SMPS.
The IPP90R500C3 is a 900 V CoolMOS power transistor from Infineon, designed for high‑frequency SMPS, quasi‑resonant flyback/forward topologies, and consumer applications. It features ultra‑low gate charge, high peak current capability, and RoHS‑compliant Pb‑free lead plating.
The document provides maximum ratings, thermal characteristics, static and dynamic electrical parameters, gate‑charge data, safe operating area, and package dimensions for the PG‑TO220 package. Typical applications include industrial SMPS and power conversion circuits.
| Continuous Drain Current (Id) | 11 A (typ) at 25 °C |
|---|---|
| Pulsed Drain Current (Id,pulse) | 24 A at 25 °C |
| Total Gate Charge (Qg) | 68 nC |
| Package | PG‑TO220 |
The maximum continuous drain current is 11 A at 25 °C.
It is supplied in a PG‑TO220 package.
Yes, it is Pb‑free lead plated and RoHS compliant.
