TLE 6258-2 LIN Transceiver Automotive Power data sheet, introduces the features and characteristics of the device
The TLE 6258-2 is a single‑wire LIN transceiver designed for automotive and industrial applications. It interfaces a protocol controller with the LIN bus and includes a standby mode with wake‑up capability.
Key features include compatibility with LIN specifications 1.2‑2.0, ISO 9141 functions, up to 20 kBaud transmission rate, low standby current, short‑circuit protection, and over‑temperature protection. Typical applications use a 1 kΩ termination resistor, a series diode, and a 1 nF capacitor in the master node to ensure reliable bus operation.
| Supply voltage (Vcc) | 4.5 V – 5.5 V |
|---|---|
| Battery supply voltage (Vg) | 6 V – 35 V |
| Bus input voltage (Vous) | -20 V – 32 V |
| Stand‑by mode current consumption (Ig) | 18 µA – 40 µA |
| Recessive state current (Toc) | 0.4 mA – 0.7 mA |
| Dominant state current (Toc) | 0.4 mA – 0.8 mA |
| Maximum junction temperature | -40 °C – 150 °C |
| Transmission rate | up to 20 kBaud |
The device supports a transmission rate of up to 20 kBaud.
