The VARISPEED-616G5 series inverter is a user-friendly inverter that features standard vector control on top of the V/F control of a general inverter. This manual describes the installation, operation, maintenance, and inspection of vector VS-616G5. Please read this manual carefully before using it. Also, be sure to use this product after familiarizing yourself with its safety precautions.
This manual provides detailed safety symbols, general precautions, installation guidelines, operating conditions, and maintenance procedures for the YASKAWA VARISPEED‑616G5 variable‑frequency drive. It includes warnings, wiring instructions, and recommended handling to prevent injury and equipment damage.
The document also lists technical specifications such as input voltage, output power, and physical dimensions, and offers a comprehensive index of functions and diagnostic codes for service technicians. This manual is written in Chinese.
| 200 V rating power range | 0.4‑75 kW (1.2‑110 kVA) |
|---|---|
| 400 V rating power range | 0.4‑300 kW (1.4‑460 kVA) |
| Input voltage | AC 3‑phase 200‑220 V 50 Hz / 200‑230 V 60 Hz |
| Output rating | AC 3‑phase 0‑230 V 1.2 kVA 3.2 A |
| Weight | 3.0 kg |
The drive accepts three‑phase AC input of 200‑220 V at 50 Hz or 200‑230 V at 60 Hz.
