The AD9287 integrates four 8‑bit ADC channels in a compact 48‑lead LFCSP package. It operates from a single 1.8 V supply and provides serial LVDS output, making it suitable for space‑constrained, low‑power applications such as medical imaging, ultrasound and high‑speed data acquisition.
Key features include 133 mW power per channel at 100 MSPS, 295 MHz full‑power analog bandwidth, programmable clock and data alignment, and built‑in digital test pattern generation. The device is specified over an industrial temperature range (‑40 °C to +85 °C).
| Resolution | 8 Bits |
|---|---|
| Power per channel | 133 mW |
| Analog bandwidth | 295 MHz |
| Input voltage range | 2 Vp‑p differential |
| Supply voltage | 1.8 V |
The AD9287 operates from a single 1.8 V supply (AVDD = 1.8 V, DRVDD = 1.8 V).
The device can sample up to 100 MSPS.
Four ADC channels are integrated into a single package.
The analog bandwidth is 295 MHz at full power.
