ADG1408/ADG1409 are 8-channel ±15V/±12V/±5V iCMOS multiplexers, with a maximum on resistance of 4.7 Ω, 0.5 Ω on resistance flatness, a maximum continuous current of 190 mA, and are compatible with 3V logic levels. They support ±15V/±12V/±5V operating voltages and are available in 16-lead TSSOP and 4mm × 4mm LFCSP packages.
The ADG1408 and ADG1409 are monolithic CMOS analog multiplexers offering 8‑channel (ADG1408) and 4‑channel differential (ADG1409) switching. They feature low on‑resistance, rail‑to‑rail operation, and are compatible with 3 V logic inputs. The devices are supplied in 16‑lead TSSOP and 4 mm × 4 mm LFCSP packages.
The datasheet provides detailed specifications, including on‑resistance, leakage currents, dynamic characteristics, and recommended supply voltages (5 V, 12 V, and 15 V dual supplies). Ordering information and package dimensions are also included.
| Input high voltage (Vint) | 2.0 V min |
|---|---|
| Package options | 16‑lead TSSOP (RU‑16) or 4 mm × 4 mm LFCSP (CP‑16‑13) |
