ADG726/ADG732 is a 16-/32-Channel, 4.5 V to +5.5 V analog multiplexer with 1.8 V to 5.5 V single supply and ±2.5 V dual supply operation. It features 4.5 ohm on resistance, 0.5 ohm on resistance flatness, rail-to-rail operation, 30 ns switching times, etc.
The ADG726 (16‑channel) and ADG732 (32‑channel) are monolithic CMOS analog multiplexers that can operate from a single 1.8 V to 5.5 V supply or a dual‑supply configuration with ±2.5 V. They feature low on‑resistance (≈4 Ω typ), flat resistance matching, break‑before‑make switching and a typical switching time of 30 ns.
These devices are offered in 48‑lead chip‑scale (LFCSP) and 48‑lead thin‑quad flat‑pack (TQFP) packages and are suited for optical, data‑acquisition, communication, audio/video, battery‑powered, medical and test‑equipment applications.
| Supply Voltage (single‑supply) | 1.8 V to 5.5 V |
|---|---|
| Supply Voltage (dual‑supply) | +2.5 V dual‑supply operation |
| Switching Time | 30 ns |
| Bandwidth (ADG726) | 34 MHz typ |
| Bandwidth (ADG732) | 18 MHz typ |
| Package Options | 48‑lead LFCSP (CP‑48) or 48‑lead TQFP (SU‑48) |
It can operate from a single 1.8 V to 5.5 V supply or from a dual‑supply of ±2.5 V.
They have a typical switching time of 30 ns.
The ADG726 is offered in a 48‑lead chip‑scale package (CP‑48) and a 48‑lead thin‑quad flat‑pack (SU‑48).
