Adg884 is a low voltage CMOS device containing two independently selectable single-pole, double-throw (SPDT) switches. It features a 0.5 Ω ultralow on resistance, a 0.1 Ω typical RON flatness, a 0.15 Ω maximum RON flatness, a 400 mA continuous current carrying capability and a 600 mA peak current. It operates at 1.8 V to 5.5 V and offers excellent audio performance with ultralow distortion. The device is ideally suited for use in mobile devices and other portable applications.
The ADG884 is a low‑voltage CMOS device that contains two independently selectable single‑pole, double‑throw (SPDT) switches. It operates from 1.8 V to 5.5 V, offers ultralow on‑resistance (0.28 Ω typ, 0.41 Ω max) and can handle up to 400 mA continuous or 600 mA peak current, making it suitable for space‑constrained, battery‑powered applications.
Typical applications include cellular phones, PDAs, MP3 players, power routing, PCMCIA cards, modems, audio/video signal routing, and other communications systems. The part is offered in 10‑ball WLCSP, 10‑lead LFCSP_WD, and 10‑lead MSOP packages.
| Operating voltage range | 1.8 V to 5.5 V |
|---|---|
| Continuous current | 400 mA |
| Peak current | 600 mA (at 5 V) |
| Input low voltage (digital) | ≤ 0.8 V |
| Total Harmonic Distortion (THD) | 0.017 % typ |
| Typical power consumption | < 0.1 pW |
It can carry 400 mA continuously and up to 600 mA peak at a 5 V supply.
