The ADG736 is a low voltage 2.5Ω dual SPDT switch suitable for applications with a single supply voltage of 1.8V to 5.5V. It features low resistance, high bandwidth, fast switching times, and TTL/CMOS compatibility.
The ADG736 is a dual, independently selectable CMOS single‑pole double‑throw (SPDT) analog switch designed for low power dissipation, fast switching, low on‑resistance and wide bandwidth. It operates from a single 1.8 V to 5.5 V supply and is offered in a 10‑lead MSOP package, making it suitable for portable, battery‑powered instruments and video/audio routing applications.
The document provides full electrical specifications, absolute maximum ratings, pin descriptions, typical performance graphs, and an ordering guide. It also lists typical applications such as USB signal switching, cell phones, PDAs, and audio/video routing.
| Bandwidth (-3 dB) | 200 MHz |
|---|---|
| Power Consumption (ibp) | 0.001 µA typ |
The ADG736 operates from a single 1.8 V to 5.5 V supply.
The device provides a bandwidth greater than 200 MHz (‑3 dB).
It is available in a 10‑lead MSOP package.
