AD8036/AD8037 is a high-speed, low-distortion, dual-output, single-supply, high-precision operational amplifier from ADI. It features input terminals with adjustable input clamp voltage and output terminals with adjustable output clamp voltage, and can be used in current sensing, voltage sensing, battery management, voltage detection, and high-precision ADC drive applications.
The AD8036 and AD8037 are voltage‑feedback clamp amplifiers designed for applications that require low distortion and high speed. They feature a patented CLAMPIN™ input architecture that provides clamp errors of typically 3 mV, over‑drive recovery in 1.5 ns, and a wide 240‑270 MHz small‑signal bandwidth.
Both devices are offered in industrial‑grade plastic DIP, SOIC, and Cerdip packages, with military‑grade options for the AD8036. Detailed electrical characteristics, absolute maximum ratings, and ordering information are provided, along with evaluation‑board layout diagrams.
| Small‑Signal Bandwidth | 240 MHz (AD8036) / 270 MHz (AD8037) |
|---|---|
| Slew Rate | 1500 V/ps (typ) |
| Input Offset Voltage | 2 mV (typ) |
| Operating Supply Range | +3 V to +5 V (typ) |
The clamp error is typically 3 mV or less.
They are offered in 8‑lead plastic DIP, SOIC, and Cerdip packages, with industrial and military temperature grades.
Yes, they are ESD‑sensitive; discharges up to 4000 V can cause damage, so proper ESD precautions are required.
