AD8009 is a low distortion amplifier produced by Analog Devices with a peak slew rate of 5500V/µs and a rise time of 545ps. It is suitable for pulse amplifier and other applications.
The AD8009 is a current‑feedback amplifier designed for pulse‑amplifier, high‑resolution video, and high‑speed instrumentation applications. It offers a 5,500 V/µs slew rate, 1 GHz small‑signal bandwidth, and low distortion across a wide frequency range.
Available in 8‑lead SOIC and 5‑lead SOT‑23 packages, the device operates from –40 °C to +85 °C (A‑grade) or 0 °C to 70 °C (J‑grade) and provides up to 175 mA output current with 10 dBm output power at 70 MHz.
| Slew Rate | 5,500 V/µs |
|---|---|
| Small‑Signal Bandwidth | 1 GHz (G=+1) |
| Large‑Signal Bandwidth | 440 MHz (G=+2) |
| Gain Flatness | 0.1 dB |
| Output Current | 175 mA |
| Operating Supply Voltage | +5 V to +6 V |
The AD8009 has a slew rate of 5,500 V/µs.
The device can deliver up to 175 mA of output current.
The A‑grade (R) package operates from –40 °C to +85 °C, while the J‑grade (RT) package operates from 0 °C to 70 °C.
