AD8137 is a low-cost, low-power 12-bit differential ADC driver with fully differential input and output, low power consumption, and high-speed performance.
The AD8137 differential driver provides fully differential outputs, adjustable gain, and a power‑down feature for low‑power applications. It operates from 2.7 V to 12 V and is available in an 8‑lead SOIC package and a 3 mm × 3 mm LFCSP.
Typical applications include portable instrumentation, battery‑powered devices, single‑ended‑to‑differential conversion, and video amplification. The datasheet includes specifications, pin descriptions, performance curves, and ordering information.
| Quiescent supply current (typical) @ 5 V | 2.6 mA |
|---|---|
| Supply voltage range | 2.7 V to 12 V |
| Slew rate | 450 V/µs |
| Input offset voltage (typical) | 2.6 mV |
| Output current | 20 mA |
The typical quiescent supply current is 2.6 mA at a 5 V supply.
The device is rated for a maximum supply voltage of 12 V.
