This document is a guarantee certificate for the VL1205 SBC VL1205 SBC product, which includes information such as the model, serial number, and date of purchase.
This manual describes the Philips VL1205 Wireless TV Link Receiver, which receives video signals from a Philips Wireless TV Link transmitter (SBC VL1200). It explains how to install the receiver, connect it via SCART, and operate it with a third TV using the included remote control and channel selector.
Safety precautions, power‑adapter requirements, channel‑selection guidance, and a full troubleshooting section are included, along with technical specifications such as dimensions, power consumption, and RF characteristics.
| Dimensions | 204 mm (W) × 168 mm (D) × 65 mm (H) |
|---|---|
| Power supply | 220‑240 V AC / 50 Hz via power adapters |
| Operating consumption | 3 W |
| Connection | SCART output: Stereo Audio / CVBS Video |
| Video standards supported | PAL / NTSC / SECAM |
| Carrier frequency (video) | 2.4 GHz |
| Number of channels | 4 (may be less, depending on local regulations) |
| Modulation (video) | FM |
| Transmission power (video) | <10 mV |
| Antenna (video) | Built‑in |
| Carrier frequency (remote extender) | 433.92 MHz |
| Modulation (remote extender) | AM |
| Transmission power (remote extender) | <10 mV |
| IR reception range | Up to 7 m |
There is no limit; you can connect three or even four receivers to a single SBC VL1200 transmitter.
Use the supplied AC adapter rated 230‑240 V AC, 50 Hz with an output of 9 V DC at 300 mA.
