ICODE SLI-S is a smart label IC from NXP company that supports ISO 15693, ISO 18000 and HF EPCglobal/Auto ID standards. It offers password-protected memory access that can be tailored to meet your specific needs. In addition, the ICODE SLI-S features increased user memory. So you can use 32-bit or 64-bit passwords for even higher security in your applications.
The ICODE SLI‑S is a passive HF RFID IC designed for secure, item‑level tagging in libraries, rental services, fashion, pharmaceuticals and other applications. It offers optional, configurable password‑protected memory for read/write, EAS and privacy‑related functions, and supports 32‑bit or 64‑bit passwords.
Key specifications include 2048 bits of on‑chip memory, 64‑bit UID, 96‑bit EPC, 1280 bits programmable user memory, and operating distances up to 2 m. The device complies with ISO 15693, ISO 18000‑3 and EPCglobal HF Class 1 standards, and can handle up to 200 tags per second in multi‑label operation.
| On‑chip memory | 2048 bits |
|---|---|
| UID size | 64 bits |
| EPC size | 96 bits (OTP) |
| Programmable user memory | 1280 bits |
| Operating distance | up to 2 m |
| Tag read rate (EPC protocol) | up to 200 tags/sec |
| Resonance capacitance | 23.5 pF / 97.0 pF |
| Write endurance | 100 000 cycles |
It offers optional, configurable password‑protected memory for read/write, EAS and privacy‑related applications, including password‑protected EAS functionality.
The IC can be read at distances up to 2 meters.
It supports up to 200 tags per second according to the EPC protocol (up to 60 tags/sec with the ISO protocol).
The device complies fully with ISO 15693, ISO 18000‑3 and EPCglobal HF Class 1 standards.
