This document is the manual for the SSW-03 Plus soft-starter series. It provides detailed information about the product's parameters, error messages, and status.
This manual provides complete instructions for the WEG SSW-03 Plus soft‑starter, covering safety notices, mechanical and electrical installation, wiring configurations (standard three‑cable and six‑cable delta), and optional devices such as the MAC‑0x module. Detailed parameter tables, error messages, and commissioning procedures are included.
The guide also describes how to use the HMI‑3P interface, SuperDrive PC software, and field‑bus options for configuration and monitoring, and supplies a spare‑part list, technical characteristics, and conformity information.
| Rated current options | 120 A, 170 A, 205 A, 255 A, 290 A, 340 A, 410 A, 670 A, 800 A |
|---|---|
| Rated voltage | 380 V |
The MAC‑0x current‑acquisition module must be installed to maintain motor protection when a bypass contactor is used.
