WEG SSW-07 Soft-Starter User Manual

This document is a user's guide for the SSW-07 E-S-P3 soft-starter, providing information on its installation, connection, and usage.

Brand: WEG
Category: Motor
Document type: User Manual
Language: English
Pages: 150
File format: PDF
File size: 5 MB
Published: 31 March, 2012
Updated: 29 September, 2023
MD5 checksum: 87A983D4F2A59E5D0D0097727174FCD1
PDF: WEG SSW-07 Soft-Starter User Manual PDF

About this manual

The WEG SSW-07 Soft‑Starter User Manual provides detailed safety instructions, installation steps, wiring diagrams and configuration procedures for the SSW-07 series. It is intended for qualified personnel who install, commission, operate and maintain the device.

The manual also includes programming data, optional accessories, technical characteristics and a troubleshooting section to help resolve common faults and perform preventive maintenance.

What's inside

Safety Instructions
General Information
Installation and Connection
Setting the SSW-07
Programming Information and Suggestions
Solutions and Troubleshooting
Options and Accessories
Technical Characteristics

Specifications

Nominal current (A) – 17 A model	17
Maximum cable size for 30 A model	6 mm² (AWG 10)
Control voltage range	94 Vca – 264 Vca
Maximum start cycles per hour (no ventilation)	10

Frequently asked questions

What cable size is recommended for a 30 A SSW‑07 model?

A minimum of 6 mm² (AWG 10) copper cable is recommended for the 30 A model.

How many start cycles per hour are allowed without a ventilation kit?

Up to ten start cycles per hour are allowed for models up to 30 A when no ventilation kit is installed.

What is the control voltage range for the soft‑starter?

The control voltage range is 94 Vca to 264 Vca (‑15 % to +10 %).

Download PDF (5 MB)
