Topstar TM-848P(L)/865GV(L) Motherboard User Manual

This document is a manual for the TM-845G REV 1.0 product. The product features multiple interfaces and functions, including keyboard interface, printer interface, game interface, VGA interface, mouse interface, audio interface, USB interface, LAN interface, etc. Additionally, the product also includes various power connectors and power indicator lights.

Brand: Topstar
Category: Motherboard
Document type: User Manual
Language: Japanese
Pages: 48
File format: PDF
File size: 8.5 MB
Published: 05 April, 2012
Updated: 29 September, 2023
MD5 checksum: 69332C8C3B683FBE2F67D8F1710EBA95
PDF: Topstar TM-848P(L)/865GV(L) Motherboard User Manual PDF

About this manual

This manual describes the features of the Topstar TM-848P(L)/865GV(L) motherboard, including supported CPUs, memory capacity, audio codec, and expansion interfaces. It also lists the accessories supplied with the board.

The guide covers detailed installation procedures, BIOS setup, driver installation, and safety precautions. An appendix provides a glossary of technical terms and a debug reference table. This manual is written in Japanese.

What's inside

Motherboard Features
Installation Guide
Program Installation
BIOS Settings
Debug Reference Table
Appendix

Specifications

Front Side Bus	Up to 800 MHz
Maximum Memory	2 GB DDR
Board Size	ATX 304.7 mm × 200.2 mm
Chipset	Intel 848P/865GV + FW82801EB
USB Ports	6
Audio Codec	AC'97 six‑channel

Frequently asked questions

What safety precaution should be taken before operating the motherboard?

Do not operate the product before proper static‑electricity protection is applied.

How many USB ports does the motherboard provide?

The board provides six USB ports.

What type of audio output is supported?

It supports an AC'97 six‑channel audio codec.

Is a BIOS password required for access?

A BIOS password can be set for administrator access.

Download PDF (8.5 MB)
