This is a motherboard specification. It includes information about the model, brand, features, and specifications.
This manual introduces the Topstar TM‑A9M motherboard, its features, safety precautions, and hardware specifications. It includes warnings about moisture, static electricity, power voltage (220 V), and temperature limits (below 60 °C) before handling the board.
The document is organized into chapters covering hardware installation steps, CPU and memory installation, jumper settings, interface descriptions (USB, SATA, PCIe, audio, rear panel), driver installation for chipset, graphics, LAN and audio, BIOS configuration and upgrade procedures, and an appendix with nationwide service office contacts. This manual is written in Chinese.
| Chipset | ATI RS690+SB600 |
|---|---|
| Supported Processors | AMD Socket 940 Athlon64FX/64X2/64, Sempron |
| Integrated Graphics | Radeon X700 |
| PCIe Support | PCIe x16 graphics slot |
| Storage Interfaces | ATA133/100/66/33, SATA2 |
The board supports AMD Socket 940 Athlon64FX/64, Athlon64 FX2, Athlon64 X2, and Sempron processors.
The motherboard has four native USB 2.0 ports and can be expanded to a total of eight USB 2.0 ports.
