This document provides detailed information on the DS4560+ thermal shutdown product, including model, package, pin arrangement, functional characteristics, etc.
This Maxim DS4560 datasheet provides a complete set of specifications for the DS4560 power‑MOSFET controller, including absolute maximum ratings, recommended operating conditions, and detailed electrical characteristics. Pin descriptions such as SHUTDOWN, TIMER, VRAMP, and ILIM are listed with their functions and typical circuit connections.
The document also covers thermal shutdown with autoretry behavior, mode‑of‑operation options, and various TIMER pin configurations (no connection, delayed enable, enable/disable, and enable with delay/disable). Package information and revision history are included at the end of the file.
| Current Limit (RILIM) | 20‑400 Ω |
|---|---|
| UVLO Rising Threshold | 7.5‑8.5 V |
| On‑Resistance (Rds(on)) | 25‑32 mΩ |
| TIMER Turn‑On Voltage | 2.6‑5 V |
The DS4560 is specified for operation from –40 °C to +135 °C.
The UVLO falling threshold is specified as 6.5 V to 7.5 V.
