InfiniiVision 7000B Series oscilloscopes are developed by Agilent Technologies. They have advanced technology and can show more tiny signal details and more occasional events than any other oscilloscopes on the market. The series has 14 models, with bandwidth up to 1 GHz. Each model has a 12.1-inch XGA LCD display and is very lightweight, only 6.5 inches deep and 13 pounds.
The InfiniiVision 7000B series offers up to 1 GHz bandwidth, 4 GSa/s sampling rate and an 8 Mpts deep memory across 4 analog channels. All models feature a 12.1‑inch XGA LCD with 256 brightness levels and hardware‑accelerated serial‑bus decoding for up to 20 protocol channels.
The series includes optional software modules for I2C, SPI, CAN/LIN, FlexRay, MIL‑STD‑1553 and more, as well as accessories such as FPGA dynamic probes, segmented memory kits and safety‑environment options. Detailed ordering information, power specifications and environmental ratings are provided for each model. This manual is written in Chinese.
| Maximum bandwidth | 1 GHz |
|---|---|
| Maximum sampling rate | 4 GSa/s |
| Display size | 12.1‑inch XGA LCD |
| Trigger output delay | ~17 ns |
| Power consumption (max) | 120 W |
| Operating temperature range | -10 °C to +55 °C |
The series provides up to 1 GHz of bandwidth.
Up to 20 serial protocol channels can be shown at once.
Option N5423A adds hardware‑accelerated I2C/SPI serial decoding.
