The Agilent U1250A series of handheld digital multimeters provides 4.5-bit resolution, 50,000-point full-scale and up to 0.025% basic DC voltage accuracy. It also provides true RMS, dBm and AC+DC readings, accurate measurement of both sinusoidal and non-sinusoidal waveforms. The series instruments provide many of the functions expected of a benchtop multimeter, including temperature measurement, frequency measurement, 4-20 mA process loop measurement and % readings, 20 MHz frequency counter (only U1252A) and dBm measurements. These instruments also provide data storage capabilities that can be accomplished manually or automatically using the optional PC interface cable. The bundled Agilent graphical user interface (GUI) further extends the potential of these instruments, allowing customization of your own data recording needs. Other features include comprehensive math functions that allow users to process the acquired data. The U1252A can be used as a programmable arbitrary waveform generator to simulate electronic circuits for debugging.
The U1251A/U1252A series offers 5‑digit (50 000 count) resolution with a basic DC accuracy of 0.025 % and true‑RMS measurement capability. It includes temperature measurement (J‑type and K‑type), 20 MHz sampling, and a programmable square‑wave generator.
Designed for rugged use, the meters meet IEC 61010‑1 Category II 1000 V safety standards and operate from –20 °C to +55 °C. The manual covers specifications, operation, data logging via USB, and warranty information. This manual is written in Japanese.
| Frequency range | 20 Hz – 100 kHz (up to 200 kHz for some functions) |
|---|---|
| Temperature operating range | -20 °C to +55 °C |
| Basic DC accuracy | 0.025 % of reading |
| True‑RMS capability | Yes |
| Warranty | 1 year standard + 2 years extended |
It operates from –20 °C to +55 °C.
The maximum DC voltage measurement is 50 000 V.
Yes, it provides true‑RMS measurement.
The warranty is 1 year with an optional 2‑year extension.
