Provide detailed information about Vintage-PE2, including specifications, interfaces, power supply, etc.
This guide explains the front and rear panel connectors of the Vintage-PE2, including USB, VGA, audio, and IDE ports, as well as the power switch and voltage selection. It details how to set the correct input voltage (115 V or 230 V) using the built‑in selector.
Step‑by‑step procedures are provided for removing the side and front panels, installing the CPU and DDR DIMM modules, attaching the CPU fan with its power connector, and re‑assembling the chassis. Safety notes warn against forcing components and highlight the importance of connecting the CPU_FAN1 power header. This manual is written in Chinese.
| Voltage selection switch positions | 115 V / 230 V |
|---|---|
| Power supply type | PFC power supply |
| Floppy drive slot size | 3.5" |
| Device bay size | 5.25" |
Place the heatsink on the CPU, align the four clips with the motherboard holes, secure them, and connect the CPU_FAN1 power connector; otherwise the system may overheat.
After all components are installed, align the side‑panel lock, insert the remaining screw, and tighten it to secure the panel.
