S-presso V1 C1686 is a desktop motherboard produced by ASUS. It uses the AM2+ interface and supports dual-channel DDR2 memory, with a maximum capacity of 8GB.
This Service Manual covers the installation and configuration of the ASUS S-presso V1 C1686 system. It includes contact information for ASUS support centers worldwide and a detailed table of contents that guides users through BIOS settings, power options, boot configuration, and hardware monitoring.
Key sections describe BIOS menus such as CPU Configuration, Chipset, Onboard Devices Configuration, PCI PCIPnP, and USB Configuration, as well as utilities like InstantOn, PC Probe, Drivers menu, and Utilities menu. Audio capabilities are listed, including SoundMAX codec, MIDI support, and DVD audio formats (AC3, SPDIF, PCM). This manual is written in Chinese.
| Audio Codec | SoundMAX |
|---|---|
| Audio Formats | AC3, SPDIF, PCM |
