This document describes the communication functions of the INP-TN512644c-E microcontroller, including RS-485 Z-ASCII type communication. The document provides detailed information on communication specifications, connections, and wiring.
The Fuji Electric PXR provides RS‑485 communication functions for connecting up to 31 slave stations to a master station. It uses the Z‑ASCII protocol and supports 9600 bps transmission speed with selectable parity and 8‑bit data length.
The manual covers communication functions, specifications, wiring, configuration of communication parameters, command/response frames, address map, sample program, troubleshooting, and an ASCII code appendix.
