INZ-TN3ZKJ-C is the instruction manual of the INZ-TN3ZKJ-3 product of INZ brand. This product has 1 input, 1 output, 1 switch, and the rated power is AC250V/3.15A. The weight is 2 kg and the dimensions are 110 mm×110 mm×210 mm
This manual covers all essential information for safely installing, operating, and maintaining the Fuji Electric ZKJ-3 external gas analysis device. It includes detailed safety precautions, wiring and piping instructions, and step‑by‑step procedures for calibration and routine checks.
The document also describes the instrument’s measurement capabilities, power requirements, and recommended handling practices to prevent accidents such as fire or explosion. Users are guided through panel functions, calibration settings, and troubleshooting to ensure reliable performance in industrial environments. This manual is written in Japanese.
| Maximum number of components | Up to 5 (up to 4 without O₂) |
|---|---|
| Power supply | AC 250 V, 15 A |
The device must not be installed in explosive or flammable atmospheres and all installation work must follow the safety guidelines to avoid fire or explosion.
It can simultaneously measure up to five gas components, or up to four components if O₂ is not included.
The instrument requires an AC supply of 250 V with a maximum current of 15 A.
