Netcore 7801NS Three‑Layer Switch CLI User Manual

This manual introduces the CLI command line operation of Netcore 7801NS three-layer switch, including preface, CONSOLE management, TELNET management, general commands, set commands, copy commands, show commands and enable commands.

Brand: Netcore
Category: Network Switches
Document type: User Manual
Language: Chinese
Pages: 144
File format: PDF
File size: 444 KB
Published: 20 March, 2012
Updated: 30 September, 2023
MD5 checksum: 451E4B591FD3B3C700CB39670F16509B
PDF: Netcore 7801NS Three‑Layer Switch CLI User Manual PDF

About this manual

This manual provides detailed instructions for operating the Netcore 7801NS three‑layer switch via its Command Line Interface (CLI). It includes sections on console access, Telnet remote login, and a full list of configuration commands for ports, VLANs, SNMP, routing, QoS, security, and more.

The document also describes how to view current settings with show commands, clear configuration entries, and troubleshoot the device. All commands are presented with syntax examples and usage notes for administrators and technicians. This manual is written in Chinese.

What's inside

Console Access
Telnet Access
General Commands
Set Commands
Show Commands
Clear Commands
Security Commands
Capture Commands
VLAN Configuration
QoS Configuration

Frequently asked questions

How can I clear a static MAC entry in the security table?

Use the command `clear security static‑mac ` where is between 1‑4094.

How do I start a Telnet session to the switch?

From a Windows command prompt, run `telnet 192.168.4.1`.
