Netcore 7226NS 24 + 2G is a smart switch that supports 24 10/100Mbps ports and 2 10/100/1000Mbps ports. It has a variety of features, including VLAN, IGMP snooping, QoS, and port mirroring.
This manual describes the hardware features of the Netcore 7226NS 24+2G smart switch, including 24 10/100 Mbps ports and 2 10/100/1000 Mbps uplink ports, Auto‑MDI/MDIX, 8 K MAC address table, and LED status indicators. Power requirements are 220 V AC at 50 Hz and the device complies with FCC Class A and CE standards.
Configuration sections cover port‑based VLANs (up to 32 VLANs), IGMP snooping, QoS settings, and console access via an RS‑232 port (9600 baud). The manual also provides wiring diagrams, LED meanings, and troubleshooting tips for reliable network operation. This manual is written in Chinese.
| Port Speed | 24 ports 10/100 Mbps, 2 ports 10/100/1000 Mbps |
|---|---|
| Maximum Frame Size | 1552 bytes |
| Power Supply | 220 V AC, 50 Hz |
| VLAN Support | 32 port‑based VLANs |
It supports up to 32 port‑based VLANs.
The switch requires a 220 V AC power source at 50 Hz.
