KVR1066D3S8N7K2/4G 4GB (2GB 1Rx8 256M x 64-Bit x 2 pcs.) PC3-8500 CL7 240-Pin DIMM Kit is a 2GB 1Rx8 256M x 64-Bit DDR3-1066 CL7 SDRAM (Synchronous DRAM) memory module from ValueRAM with a total capacity of 4GB.
The KVR1066D3S8N7K2/4G kit consists of two 2 GB DDR3‑1066 (PC3‑8500) 240‑pin DIMM modules, providing a total capacity of 4 GB. Each module uses 1Rx8, 256M × 64‑bit organization and operates at a standard 1.5 V supply.
Key features include programmable CAS latency (8, 7, 6), internal self‑calibration via the ZQ pin, on‑die termination (ODT), 8‑bit pre‑fetch, and a 533 MHz fCK clock. The modules meet JEDEC standards, have gold‑plated contacts, and are rated for operation from 0 °C to 85 °C.
| Total Kit Capacity | 4 GB (2 × 2 GB modules) |
|---|---|
| Memory Speed | 533 MHz fCK (DDR3‑1066) |
| Operating Voltage | 1.5 V (1.425 V ~ 1.575 V) |
| CAS Latency Options | 8, 7, 6 |
| Power Consumption (per module) | 0.725 W |
| Operating Temperature | 0 °C ~ 85 °C |
| PCB Height | 1.18 in (30 mm) |
The kit provides a total capacity of 4 GB, made up of two 2 GB modules.
It operates at a JEDEC‑standard 1.5 V (range 1.425 V ~ 1.575 V).
The module supports programmable CAS latency values of 8, 7, and 6.
It can operate from 0 °C up to 85 °C.
