The BSN 70 L302 I copper/iron construction impregnated (HID standard) inductive ballast is suitable for HID light sources, in combination with an external trigger.
This manual describes the Philips BSN70L3021 HID ballast, intended for use with HID light sources and compatible external switches. It includes general and operating parameters, connection requirements, temperature limits, and product identification details.
Key data such as input voltage (230 V / 50 Hz), current ratings, power factor, power consumption, dimensions, and maximum operating temperature are listed, along with certification markings and packaging information. This manual is written in Chinese.
| Input Voltage | 230 V / 50 Hz |
|---|---|
| Minimum Power Factor | 0.85 (min) |
| Maximum Operating Temperature | 130 °C (max) |
| Length (A1) | 117.0 mm |
| Width (A2) | 102 mm |
| Height (B1) | 57.1 mm |
| Depth (C1) | 51.5 mm |
| Mounting Hole Diameter (D1) | 6.2 mm |
| Net Weight | 1.100 kg |
The ballast operates on 230 V at 50 Hz.
The minimum power factor is 0.85.
